NQ100W-8 Wheel excavator
NANQIAO hydraulic wheel excavator equips self-developed axles and gearboxes. Engine brand is Wechai or Cummins.
Category:
Products
Product Accessories:
Service Hotline：
- Product Description
- Specification
-
- Commodity name: NQ100W-8 Wheel excavator
- Commodity ID: NQ100W-8
NANQIAO hydraulic wheel excavator equips self-developed axles and gearboxes. Engine brand is Wechai or Cummins.
NQ100W-8 Excavator Features
1. Powerful ability: Excavator adopts reinforced boom design to strengthen the key stress points of the thickened boom, to easily withstand the huge pressure during the construction process.
2. Comfortable cab: The Flexible and comfortable operating cab equips 360-degree surround window with excellent line of sight, easy to operate. The cab is equipped with suspended seats and a new human-computer interaction operating system.
3. Dozer blade: The wear-resistant and sturdy dozer blade usually helps push away larger obstacles during the operation and saves unnecessary manpower and material resources.
4. Lower fuel consumption: By adopting reasonable configuration and selecting the most suitable component system, we have greatly reduced fuel consumption and helped users save a lot of fuel costs.
5. Convenient maintenance: The machine adopts an integrated rear cover design. All maintenance can be carried out by opening the rear cover.
Key words:- Wheel excavator
-
RANGE OF OPERATIOIN Max digging distance 6865mm Max digging depth 4075mm Max digging height 7435mm Max dumping height 5245mm Min front radius 2250mm Min rear radius 2090mm Bulldozing width 2250mm DIMENSIONS (Length*width*height) transport status 5800*2200*2950mm Wheel base 2500mm track(front/rear) 1755mm Counterweight ground clearance 1170mm Min ground clearance 345mm TECH SPECIFICATION Max digging force 50KN Rotating angle 360° Machine weight 8880 Engine model 4DK Rated power 62kW Rated rotating speed 2200rpm Hydraulic system working pressure 21Mpa Hydraulic system flow 130L/min Max hauling force 48KN Max driving speed 31km/h Grade climbing ability 35° Tyre model 8.25-20 Bucket volume 0.2-0.4m³ Fuel consumption ≥4L/h Fuel tank volume 180L Hydraulic tank volume 165L
